Thermocouple Types Explained: K, J, T, E, N, S, R, B Comparison & Selection Guide

You need to replace a thermocouple — or spec one for a new line — and the catalog shows eight letters. K, J, T, E, N, S, R, B. Each has a different alloy pair, a different temperature ceiling, and a different set of environments where it thrives or fails.

Most thermocouple-type references list those eight letters with temperature ranges and stop there. That is not enough to make a real decision. Choosing the right type is a three-variable problem: temperature range first, then atmosphere compatibility, then accuracy class. Get the sequence wrong and you end up with a Type K degrading in a sulfur-rich furnace — or a Type T failing in a process that runs above 400°C.

Below: the comparison table you came here for, followed by a three-step selection filter and the wire color codes to identify what is already installed.

Base Metal vs Noble Metal — The Two Families

Eight standard types, two families. The split is simple: what are the wires made of?

Base metal — Types K, J, T, E, and N — nickel, chromium, iron, copper, constantan in various pairings. These handle most industrial work below 1,260°C and account for roughly 90% of thermocouple installations. Commodity pricing.

Noble metal — Types S, R, and B — platinum and platinum-rhodium. They go where base metals melt: above 1,400°C, and they double as calibration references in labs. The penalty is price — expect 10–50× the cost of a comparable base metal assembly.

Rule of thumb: if your continuous process temperature stays below 1,200°C, start with base metals. Go noble only when the temperature forces you.

Thermocouple Types Comparison Chart

All eight ANSI/ASTM types in one table. Scan the ranges and atmospheres here, then use the selection framework below to narrow your pick.

Type	Alloy (+/−)	Range (°C)	Range (°F)	Class 1 Tolerance	Best Atmosphere	Common Applications
K	Chromel / Alumel	−200 to +1,260	−328 to +2,300	±1.5°C or ±0.4%	Oxidizing, inert	General process, kilns, exhaust gas, food processing
J	Iron / Constantan	−210 to +760	−346 to +1,400	±1.5°C or ±0.4%	Reducing, vacuum	Heat treating, plastics, older industrial equipment
T	Copper / Constantan	−200 to +370	−328 to +700	±0.5°C or ±0.4%	Oxidizing, reducing, inert	Cryogenics, food, HVAC, environmental monitoring
E	Chromel / Constantan	−200 to +900	−328 to +1,650	±1.5°C or ±0.4%	Oxidizing, inert	Cryogenics, power generation, low-to-moderate temp
N	Nicrosil / Nisil	−200 to +1,260	−328 to +2,300	±1.5°C or ±0.4%	Oxidizing, inert, sulfur-containing	Furnaces, heat treatment, replacing K in harsh service
S	Pt-10%Rh / Pt	0 to +1,600	+32 to +2,912	±1.0°C or ±[1+0.003(t−1100)]°C	Oxidizing, inert	Laboratory reference, glass, semiconductor
R	Pt-13%Rh / Pt	0 to +1,600	+32 to +2,912	±1.0°C or ±[1+0.003(t−1100)]°C	Oxidizing, inert	Industrial high-temp, continuous casting, steel
B	Pt-6%Rh / Pt-30%Rh	+250 to +1,700	+482 to +3,092	±4°C (600–1,700°C)	Oxidizing, inert	Glass melting, sintering, very high temp furnaces

Type-by-type notes:

Type K — the workhorse. Broadest useful range among base metals, handles oxidizing atmospheres (air) without complaint. The catch: “green rot.” In reducing or low-oxygen gas between 800°C and 1,050°C, the Chromel leg undergoes selective oxidation and drifts badly. Keep K out of sulfur and reducing environments.

Type J — iron positive leg, so it actually thrives where K fails: reducing atmospheres and vacuum. You pay for that with a lower ceiling (760°C continuous) and shorter life at elevated temps because iron rusts. Still widely installed in legacy plastics and heat-treatment lines.

Type T — tightest accuracy of any base metal: ±0.5°C Class 1 tolerance. The copper leg gives rock-solid stability down to −200°C, which is why T dominates cryogenics, food cold chain, and pharmaceutical monitoring. Ceiling is only 370°C — the lowest of the group.

Type E — highest thermoelectric output per degree of any standard type (68 µV/°C at 0°C), so the signal-to-noise ratio at moderate temperatures is hard to beat. Runs clean in oxidizing and inert gas. Good cryogenic performer alongside T.

Type N — think of it as “K without the drama.” Same temperature range, but Nicrosil/Nisil alloys shrug off the sulfur attack and short-range ordering that eat K over time. Plants that were burning through K thermocouples every few months in heat-treatment furnaces often see 2–3× longer life after switching to N.

Type S — the international calibration reference from 0°C to 1,600°C. Platinum construction means excellent stability, but the output is low (~10 µV/°C), so you need clean signal conditioning. Mostly labs and semiconductor crystal growth.

Type R — slightly higher output than S (13% rhodium vs 10%) and more at home on the factory floor: continuous casting, steel processing, glass.

Type B — highest temp ceiling at 1,700°C. Odd property: output is nearly zero below 50°C, so cold junction compensation errors basically disappear — handy in glass-melting and sintering furnaces. Cannot read anything below about 250°C.

The Three-Step Selection Framework

Don’t read through all eight types hoping one “feels right.” Run these three filters in order — each one knocks out options until one or two survive.

Step 1 — Temperature Range (Binary Filter)

The hardest constraint comes first. If a type’s continuous limit doesn’t cover your peak process temperature with margin, cross it off — no matter what else it offers.

Your Continuous Temp	Candidates
Below −40°C (cryogenic)	T, E, K, N
−40°C to +370°C	T, E, J, K, N
+370°C to +760°C	E, J, K, N
+760°C to +1,260°C	K, N
Above +1,260°C	S, R, B (noble metals only)

Step 2 — Atmosphere Compatibility (Elimination Filter)

Temperature doesn’t tell the whole story. The gas sitting around your thermocouple assembly decides how long the wire actually lasts.

Atmosphere	Safe Types	Avoid
Oxidizing (air, O₂-rich)	K, N, E, T, S, R, B	J (iron oxidizes rapidly)
Reducing / vacuum	J, T	K (green rot), N
Sulfur-containing	N, J, T	K (sulfur attacks Chromel)
Inert (N₂, Ar)	All base metals	—

Two traps we see again and again:

• Type K in reducing or sulfur gas — the single most common thermocouple misapplication in the field. K’s Chromel leg is vulnerable to preferential oxidation (“green rot”) in low-oxygen conditions and corrodes fast in sulfur-bearing gas. If sulfur is in the picture, spec Type N.
• Type J above 760°C continuous — the iron leg oxidizes fast above this temperature, cutting life to weeks or days. If you need reducing-atmosphere coverage above 760°C, pair a sheathed thermocouple with a protective metal sheath over Type N wire.

Step 3 — Accuracy Class (Confirmation)

Steps 1 and 2 should leave you with one or two candidates. Now check whether the accuracy actually meets your loop tolerance.

IEC 60584 defines two tolerance classes:

Type	Class 1 (tighter)	Class 2 (standard)
K, J, N, E	±1.5°C or ±0.4%	±2.5°C or ±0.75%
T	±0.5°C or ±0.4%	±1.0°C or ±0.75%
S, R	±1.0°C (0–1,100°C)	±1.5°C (0–1,100°C)
B	±4°C (600–1,700°C)	Not defined

If your loop lives with ±2.5°C — and most general process control does — Class 2 of any surviving candidate is fine. Need ±0.5°C at moderate temps? Type T, Class 1 wire.

Bottom line: about 90% of the time, this framework puts you on Type K (oxidizing, moderate to high temp) or Type N (same range, better where sulfur or long-term stability matters). Low temp or tight accuracy? Type T. Above 1,260°C? S, R, or B — S for the lab, R for the factory, B for the extreme end.

Wire Color Codes — ANSI vs IEC at a Glance

No documentation on the installed thermocouple? The wire insulation color tells you the type — assuming you know whether the site follows ANSI (North America) or IEC (Europe, most of Asia).

Type	ANSI Positive	ANSI Negative	IEC Positive	IEC Negative
K	Yellow	Red	Green	White
J	White	Red	Black	White
T	Blue	Red	Brown	White
E	Purple	Red	Violet	White
N	Orange	Red	Pink	White
S	Black	Red	Orange	White
R	Black	Red	Orange	White
B	Gray	Red	—	—

The quick memory rule: ANSI negative is always red. In the IEC system, the positive wire color identifies the type and the negative is always white.

Colors don’t match either standard? Someone probably rewired with generic cable. Put a multimeter across the junction at a known temperature — each type produces a different millivolt output, which nails the identification. More detail in our temperature sensor selection guide.

Thermocouples cover the high-temperature end of the range, but they are not always the right pick. For a breakdown of when an RTD makes more sense than a thermocouple — below 500°C, where accuracy and long-term stability matter — see our dedicated comparison.
